Intel Core i7-14700KF / 3.4GHz

Essentials
Product Collection Intel® Core™ i7 Processors (14th gen)
Code Name Products formerly RAPTOR LAKE
Vertical Segment Desktop
Processor Number  i7-14700KF
Lithography  Intel 7
Use Conditions  PC/Client/Tablet
CPU Specifications
Total Cores  20
# of Performance-cores 8
# of Efficient-cores 12
Total Threads  28
Max Turbo Frequency  5.6 GHz
Intel® Turbo Boost Max Technology 3.0 Frequency ‡  5.6 GHz
Performance-core Max Turbo Frequency  5.5 GHz
Efficient-core Max Turbo Frequency  4.3 GHz
Performance-core Base Frequency 3.4 GHz
Efficient-core Base Frequency 2.5 GHz
Cache  33 MB Intel® Smart Cache
Total L2 Cache 28 MB
Processor Base Power  125 W
Maximum Turbo Power  253 W
Supplemental Information
Marketing Status Launched
Launch Date  Q4'23
Embedded Options Available  No
Memory Specifications
Max Memory Size (dependent on memory type)  192 GB
Memory Types
Up to DDR5 5600 MT/s
Up to DDR4 3200 MT/s
Max # of Memory Channels  2
Max Memory Bandwidth  89.6 GB/s
Expansion Options
Direct Media Interface (DMI) Revision 4.0
Max # of DMI Lanes 8
Scalability 1S Only
PCI Express Revision  5.0 and 4.0
PCI Express Configurations ‡  Up to 1x16+4, 2x8+4
Max # of PCI Express Lanes  20
Package Specifications
Sockets Supported  FCLGA1700
Max CPU Configuration 1
Thermal Solution Specification  PCG 2020A
TJUNCTION  100°C
Package Size 45.0 mm x 37.5 mm
Advanced Technologies
Intel® Gaussian & Neural Accelerator  3.0
Intel® Thread Director  Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU  Yes
Intel® Speed Shift Technology  Yes
Intel® Turbo Boost Max Technology 3.0 ‡  Yes
Intel® Turbo Boost Technology ‡  2.0
Intel® Hyper-Threading Technology ‡  Yes
Intel® 64 ‡  Yes
Instruction Set  64-bit
Instruction Set Extensions  Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
Idle States  Yes
Enhanced Intel SpeedStep® Technology  Yes
Thermal Monitoring Technologies  Yes
Intel® Volume Management Device (VMD)  Yes
Security & Reliability
Intel® Standard Manageability (ISM) ‡  Yes
Intel® Control-Flow Enforcement Technology  Yes
Intel® AES New Instructions  Yes
Secure Key  Yes
Intel® OS Guard Yes
Execute Disable Bit ‡  Yes
Intel® Boot Guard  Yes
Mode-based Execute Control (MBEC)  Yes
Intel® Virtualization Technology (VT-x) ‡  Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ‡  Yes
Intel® VT-x with Extended Page Tables (EPT) ‡  Yes
